Wireless Electricity Meter Pulse Module (DIN Rail)
SKU: JA-150EM-DIN
- Wireless DIN rail module that makes electricity meter readings available via MyJABLOTRON Web Self-Service.
- The PU input is compatible with the S0 impulse output of class B meters according to EN 62053-31 (max. 3 m cable).
- The TA input allows remote tariff switching (max. 230 V AC).
- An additional IN input (e.g. a distribution board cover contact) with low voltage, galvanically separated from mains.
- 230 V / 50 Hz supply, typical consumption 0.5 W.
- 868.1 MHz JABLOTRON protocol; internal antenna with the option of an external AN-868 antenna.
- 1 DIN module, 68 x 96 x 18 mm.
Share:
| General Features | |
|---|---|
| Power Supply: | 230 V / 50 Hz, protection class II; typical/max. consumption 0.5 W / 1.2 W |
| Antenna: | Internal; external AN-868 antenna can be connected |
| Operating Temperature: | -20 °C to +60 °C |
| Compatibility: | JABLOTRON 100+ control panels; MyJABLOTRON |
| The Color: | White |
| Dimension: | 68 x 96 x 18 mm (1 DIN module) |
| Input Type: | PU input: S0 impulse output of class B meters per EN 62053-31 (5 V, max. 3 m); IN input: low voltage, galvanically separated; TA input: tariff, max. 230 V AC |
| Max. Current: | 10 mA |
| Radio operating frequency: | 868.1 MHz, JABLOTRON protocol |
