Wireless Wall Button
SKU: JA-158J
- Wireless wall-mounted panic and control button for JABLOTRON alarm systems.
- Can be used to trigger a panic alarm remotely.
- Allows various control functions to be performed on the alarm system.
- Can be used to remotely control compatible devices and electrical equipment.
- Can be used as a doorbell.
- Two-way communication provides visual and audible confirmation that the requested action has been successfully performed.
- Operates using the JABLOTRON 868.1 MHz wireless communication protocol.
- Compatible with JA-103K and JA-107K control panels.
- Powered by two CR2032 lithium batteries.
- Provides a wireless communication range of approximately 300 m in open space.
- Reports low battery status to the system.
- Designed for wall-mounted installation.
- Features IP22 protection.
- Security Grade 2 / Environmental Class II.
- Operating temperature range from -10 °C to +40 °C.
- Compact design with dimensions of 80 × 80 × 20 mm.
Share:
| General Features | |
|---|---|
| Weight: | 58 g |
| Standby Current: | 5 µA |
| Supply: | 2 × CR2032 lityum pil, 3 V / 0,2 Ah |
| Operating Temperature: | -10 °C ile +40 °C |
| Product Class: | Wall-Mounted Panic/Control Button |
| Product Code: | JA-158J |
| Communication: | bidirectional |
| Control Board: | JA-103K, JA-107K |
| Dimension: | 80 × 80 × 20 mm |
| Humidity: | 75% RH, non-condensing. |
| Protection Standard: | IP22 |
| Place of Utilization: | General indoor environment |
| System: | JABLOTRON |
| Security level: | Grade 2 |
| Radio operating frequency: | 868,1 |
